Pu Panel for Cold Room
TianShun
| Quantity: | |
|---|---|
As a premier manufacturer and direct supplier of temperature-control infrastructure, we engineer heavy-duty insulated wall panels designed explicitly for large-scale commercial facilities. These advanced structural elements provide unparalleled thermal resistance, ensuring your facility maintains exact climate conditions while optimizing energy expenditure.
Direct sourcing from the manufacturer ensures streamlined procurement for expansive infrastructure projects.
Engineered with high-density PIR foam to drastically reduce compressor workload and daily utility costs.
Customizable panel dimensions designed to accommodate complex architectural layouts and high-clearance environments.
Certified flame-retardant properties provide essential risk mitigation for high-value inventory and personnel.
Step into a facility fortified by our heavy-duty insulated wall panels, and you immediately sense the profound stability of a meticulously controlled environment. The tactile firmness of the color-coated or stainless steel exterior speaks to its industrial-grade craftsmanship, engineered to withstand the rigorous demands of constant forklift traffic and heavy machinery operations. Beneath this unyielding surface lies an advanced Polyisocyanurate (PIR) foam core, a marvel of modern thermal engineering that silently and continuously repels external heat infiltration. When you run your hand along the seamless joints, the precision of the tongue-and-groove integration is palpable, leaving no room for microscopic drafts or moisture seepage. There is no echoing hum of overworked compressors here; instead, the ambient quiet reflects a refrigeration system operating at peak efficiency, unburdened by thermal leaks. The panels possess a pristine, smooth finish that not only looks clinically clean but also actively resists the accumulation of frost and condensation. By choosing these structural components, facility operators are not merely erecting walls; they are investing in an impenetrable thermal fortress that drastically reduces utility expenditures, safeguards sensitive inventory, and elevates the operational integrity of the entire cold storage ecosystem.
Specification Parameter | Detail / Value |
|---|---|
Product Name | High-Density PU Cold Room Panels |
Brand | TianShun |
Model | PU Wall Panel |
Core Material | Polyisocyanurate (PIR) foam core |
Core Thickness | 50mm, 75mm, 100mm, 120mm, 150mm, 180mm, 200mm |
Core Density | 38-45 kg/m³ |
Closed-Cell Rate | >98% (forms micro vacuum compartments, completely isolates moisture and water vapor) |
Panel Width | 1000mm / 1120mm / 1130mm |
Panel Length | Customized according to customer needs |
Steel Plate Thickness | 0.4mm - 0.8mm |
Panel Material | Color-coated steel sheet / Stainless steel plate |
Coating Process | Inner and outer plates use Aluzinc or Zinc coating |
Fire Performance | Flame retardant level, surface carbonizes upon fire exposure to form a dense protective layer, self-extinguishes within 2-3 seconds after fire source is removed |
Our insulated wall panels are engineered to transform the operational dynamics of your temperature-controlled environment. By focusing on molecular-level insulation and structural integrity, we deliver a product that actively enhances your daily operations.
Acoustic and Thermal Dampening: The dense 38-45 kg/m³ core naturally absorbs ambient industrial noise while completely blocking external heat waves, creating a serene and stable internal climate.
Tactile Structural Rigidity: The 0.4mm to 0.8mm steel facings provide a solid, unyielding touch, ensuring that accidental impacts from pallet jacks or loading equipment do not compromise the insulation layer.
Micro-Vacuum Technology: With a closed-cell rate exceeding 98%, the internal foam structure acts as billions of microscopic thermoses, locking in cold air and permanently repelling vapor intrusion.
Rapid Self-Extinguishing Mechanism: In the rare event of a fire hazard, the immediate carbonization and 2-3 second self-extinguishing feature prevent catastrophic spread, offering operators profound peace of mind.
Pristine Visual Aesthetics: The flawless Aluzinc or stainless steel finish reflects lighting efficiently, brightening the storage area while presenting an immaculate, professional appearance to inspectors and auditors.
Facility operators consistently prioritize the reduction of long-term energy consumption. The foundation of our panels lies in the high-density Polyisocyanurate (PIR) foam core, boasting a precise density of 38-45 kg/m³. This meticulously calibrated density provides an exceptional R-value that redefines thermal resistance in industrial applications.
Severing Heat Transfer: The advanced PIR core acts as an absolute barrier against thermal conductivity, preventing outside ambient heat from warming your meticulously cooled interior.
Compressor Optimization: By maintaining strict temperature fidelity, these panels drastically lower the operational load on your refrigeration units, extending the lifespan of your mechanical assets.
Drastic Energy Reductions: The combination of high density and a >98% closed-cell rate translates directly into plummeting electricity expenditures, offering a rapid return on your infrastructure investment.
Vacuum-Sealed Efficiency: The microscopic vacuum compartments within the foam ensure that the insulation value does not degrade over time, providing decades of consistent thermal performance.
Industrial warehousing demands uncompromising adherence to fire safety protocols. Our panels are engineered with advanced flame-retardant properties to protect your high-value assets, personnel, and overall infrastructure from catastrophic fire damage.
Active Carbonization Shield: Upon contact with open flames, the panel surface immediately carbonizes. This dense char layer acts as an impenetrable shield, blocking the fire from reaching the inner core.
Rapid Self-Extinguishing: Once the external fire source is removed, the panel's advanced chemical composition ensures it self-extinguishes within a mere 2 to 3 seconds, halting any sustained combustion.
Regulatory Peace of Mind: Designed to meet rigorous international building and fire safety codes, ensuring your facility passes critical safety inspections without costly retrofitting.
Asset Preservation: By preventing the spread of flames, these panels safeguard highly sensitive and expensive perishable goods from smoke and fire contamination.
The integrity of a cold environment is often compromised by the invisible threat of moisture infiltration, leading to the dreaded cold bridge effect and subsequent ice buildup. We have engineered a structural envelope that eliminates these vulnerabilities entirely.
Precision Tongue-and-Groove Interlock: The edges of each panel are milled to exact tolerances, clicking together to form a seamless, airtight seal that prevents any conditioned air from escaping.
Eradication of Cold Bridges: Hidden fastener systems and exact joint geometry ensure there is no continuous metal path from the outside to the inside, completely neutralizing thermal bridging.
Absolute Vapor Barrier: The >98% closed-cell structure boasts an exceptionally low water absorption rate, acting as a permanent shield against external humidity and preventing internal wall condensation.
Frost-Free Operations: By locking out moisture, the panels prevent the dangerous and damaging accumulation of ice on walls and ceilings, maintaining a safe working environment for your staff.
Industrial environments are punishing. From the frequent impact of logistics operations to extreme temperature fluctuations, your facility's walls must possess unyielding resilience. Our panels are armored to endure decades of heavy use.
Heavy-Duty Metal Facings: Clad in 0.4mm to 0.8mm thick color-coated or stainless steel, the panels effortlessly absorb the bumps and scrapes inherent in busy forklift and pallet jack corridors.
Corrosion Immunity: The premium Aluzinc or zinc coating processes protect the steel from the highly oxidative environment of cold, damp storage, preventing rust and structural decay.
Chemical Washdown Resistance: The robust exterior surfaces are designed to withstand frequent, aggressive chemical sanitization processes without peeling, fading, or degrading.
Long-Term Dimensional Stability: Despite extreme internal-external temperature differentials, the high-density core prevents warping, bowing, or delamination, maintaining a perfectly plumb wall for the life of the building.
No two climate-controlled facilities share the exact same operational parameters. Whether you are constructing a gentle cooling room for fresh produce or a harsh -45°C blast freezer for medical supplies, architectural flexibility is paramount.
Extensive Thickness Range: With core thicknesses ranging from 50mm up to a massive 200mm, operators can select the exact thermal resistance required for their specific temperature zones.
Limitless Length Configurations: Panels are manufactured to your exact length specifications, allowing for floor-to-ceiling installations without horizontal seams, maximizing both strength and insulation.
Multi-Industry Suitability: The versatile design makes these panels the premier choice for meat processing plants, pharmaceutical cold chains, and massive centralized logistics hubs.
Adaptable Widths: Available in 1000mm, 1120mm, and 1130mm widths to perfectly align with your structural grid, minimizing waste and optimizing the installation footprint.
Project timelines dictate financial outcomes, while hygiene standards dictate operational legality. Our panels are designed to accelerate construction schedules while exceeding the strictest sanitary requirements in the food and pharmaceutical sectors.
Accelerated Modular Construction: The lightweight nature of the PIR core combined with the intuitive tongue-and-groove design allows contractors to erect massive wall spans in a fraction of the time required by traditional methods.
Reduced Labor Expenditures: Fast, straightforward installation translates directly to significantly lower manual labor costs and earlier facility commissioning.
Clinically Smooth Surfaces: The completely flat, non-porous metal facings offer zero crevices for bacteria, mold, or pathogens to harbor, ensuring a sterile environment.
Effortless Sanitization: Designed to comply with stringent FDA and USDA food-grade standards, the panels can be rapidly pressure-washed and wiped down, minimizing facility downtime during cleaning shifts.
Partnering with a dedicated manufacturer for your infrastructure needs ensures that you receive more than just physical materials; you gain a strategic advantage in facility management and operational longevity.
Uncompromising Quality Control: Every panel undergoes rigorous factory testing for density, closed-cell integrity, and coating thickness before it ever reaches your construction site.
Direct Supply Chain Efficiency: By eliminating intermediaries, we provide transparent lead times, scalable production for massive orders, and highly competitive procurement economics.
Engineering Consultation: Our technical team works directly with your architects to determine the exact panel specifications, thicknesses, and joint configurations required for your unique climate challenges.
Proven Global Reliability: Trusted by leading logistics and processing facilities worldwide, our panels have a documented history of performing flawlessly in the most demanding industrial environments.
Review these professional inquiries to better understand how our high-density insulated panels seamlessly integrate into your specific architectural and operational requirements.
How does the >98% closed-cell rate impact the long-term R-value of the facility?
The exceptionally high closed-cell rate ensures that the microscopic gas pockets within the PIR foam remain permanently sealed. This prevents moisture ingress and air exchange within the core, meaning the panel retains its original, maximum thermal resistance (R-value) for decades, preventing the gradual increase in energy costs associated with inferior insulation.
Can the Aluzinc and stainless steel coatings withstand daily chemical sanitization?
Yes. The 0.4mm to 0.8mm metal facings, particularly the stainless steel and premium Aluzinc options, are specifically engineered to resist the corrosive effects of harsh industrial cleaning agents. This makes them ideal for food processing and pharmaceutical environments where daily, high-pressure chemical washdowns are mandatory for compliance.
What is the recommended panel thickness for a deep-freeze facility operating at -30°C?
For deep-freeze applications operating at or below -30°C, we strongly recommend utilizing our 150mm, 180mm, or 200mm thick panels. The exact thickness depends on the external ambient temperature and the specific energy efficiency targets of your facility, ensuring the refrigeration units operate efficiently without overexertion.
How do the tongue-and-groove joints prevent thermal bridging?
The precision-milled tongue-and-groove edges create a deeply interlocking, labyrinth-like seal between panels. This design physically breaks the continuous path that heat or cold would typically travel through a joint. When combined with appropriate sealants, it guarantees a 100% airtight and watertight barrier, completely neutralizing thermal bridging.
Are custom panel lengths available to eliminate horizontal seams in high-ceiling warehouses?
Absolutely. We manufacture panel lengths entirely customized to your architectural requirements. Supplying single, continuous panels from the floor to the ceiling eliminates the need for horizontal joints. This not only significantly accelerates the installation process but also removes potential weak points for structural stress and thermal leakage.
